DATASHEET
Amberlite Data
Amberlite is manufactured using several high performance modified resins, including, acrylic, cross linked acrylic and PETG.
UK Standard panel size 2440mm x 1220mm x 8mm
USA standard panel size 10 x 4ft x .39 inch
Sheet Thickness:
Amberlite is available in several standard thickness levels:
• 6mm (11kg per sqm) = 1/4″ (2.23 lbs per sq foot)
• 8mm (14kg per sqm) = 5/16″ (2.79 lbs per sq foot)
• 10mm (18kg per sqm) = 3/8″ (3.62 lbs per sq foot)
• 12mm (22kg per sqm) = 1/2″ (4.46 lbs per sq foot)
Finishes:
Smooth & textured available. Polished or matt.
With a standard tolerance level of +/- 10% of nominal.
Fire Rating:
Class A flame spread classification in accordance with ASTM E84 (tested on a 10mm Marble White panel)
Performance:
Meets Class A criteria for flame spread and smoke development under ASTM E84
Standards:
Tested in accordance with ASTM E84 (equivalent to UL 723) & EN 13501-1
Application:
Suitable for interior wall and ceiling applications where Class A materials are required, subject to local code and project-specific approvals.
Based on material composition and thickness, this result is considered representative of Amber-Lite panels at 10mm and greater thicknesses, including 12mm configurations and the Elite range incorporating stone. These configurations are expected to provide comparable or improved fire performance.
